The Maglite® Blue Spectrum Mini Maglite® AA LED Flashlight is a compact, two-AA specialty flashlight that combines the familiar Mini Maglite® platform with a purpose-built blue Spectrum LED. The blue beam is designed for applications where blue illumination offers advantages over conventional white light, including low-light map and chart reading, preserving visibility of map symbols, notes and elevation markings, blood tracking, forensic work, crime-scene examination, quality inspections, and hygiene audits. Compact enough for a pocket, flight bag, field kit, hunting gear, inspection kit, or tool bag, it delivers 27 lumens, a 71-meter beam distance, 1,259 candela peak beam intensity, and runtime of 12 hours on High or 32 hours on Low. Adjustable spot-to-flood focus, LED Heat-Sink Technology, power management, aluminum construction, and a water-resistant design provide practical performance in a compact handheld package.

1. Beam and Runtime Capabilities

The Blue Spectrum Mini Maglite® AA LED produces 27 lumens of blue light on High, with an ANSI/PLATO FL 1 beam distance of 71 meters (approximately 233 feet) and 1,259 candela peak beam intensity. Rather than being designed simply to maximize conventional white-light brightness, its blue output provides specialized illumination for applications where blue light can improve visibility of particular details.

The blue spectrum is particularly useful for reading maps and charts in low-light or no-light environments because it provides detail without washing out symbols, notes, or elevation markers. The flashlight provides 12 hours of runtime on High and up to 32 hours on Low, with the Low setting producing 8 lumens for reduced-output and extended-runtime use.

• Maximum Output: 27 lumens

• Low Output: 8 lumens

• Beam Color: Blue

• Beam Distance: 71 m / approx. 233 ft.

• Peak Beam Intensity: 1,259 cd

• Runtime – High: 12 hr.

• Runtime – Low: 32 hr.

• Runtime – Eco: N/A

• Light Source: Blue Spectrum LED

2. Technology and Features in the Head of the Flashlight

The flashlight uses a specialized Blue Spectrum LED light engine rather than a conventional white LED. The blue wavelength provides task-specific illumination for pilots, field personnel, hunters, forensic personnel, crime-scene technicians, inspectors, and other users who can benefit from blue light.

The LED system incorporates LED Heat-Sink Technology to help manage heat produced by the LED and support dependable operation within the flashlight's aluminum body. Power management regulates available battery power during operation and supports the flashlight's High and Low output levels.

The head also provides Maglite®'s spot-to-flood adjustable focus. Rotating the head changes the beam from a tighter spot for directing light farther or onto a specific area to a broader flood for closer and wider-area illumination.

• LED Type: Blue Spectrum LED

• Beam Color: Blue

• Thermal Management: LED Heat-Sink Technology

• Power Management: Yes

• Beam Focus: Adjustable Spot to Flood

• Focus Control: Rotating Head

• Maximum Output: 27 lumens

• Low Output: 8 lumens

• Beam Distance: 71 m

• Peak Beam Intensity: 1,259 cd

• Head Diameter: 1 in. / 25.4 mm

3. Power/Mode Functions

Operation follows the familiar twist-head design of the Mini Maglite® platform. Twist the head to operate the flashlight and adjust the beam, allowing the user to transition between focused spot and broader flood illumination without a separate electronic tail-cap switch.

The Blue Spectrum Mini Maglite® AA LED provides High and Low output levels, with 27 lumens on High and 8 lumens on Low. The design also supports hands-free Candle Mode, allowing the flashlight to serve as a small stationary area light when hands-free illumination is useful.

• Switching: Twist-Head Operation

• High Mode: Yes

• High Output: 27 lumens

• Low Mode: Yes

• Low Output: 8 lumens

• Beam Adjustment: Spot to Flood

• Hands-Free Function: Candle Mode

• High Runtime: 12 hr.

• Low Runtime: 32 hr.

• Eco Mode: No

• Electronic Multi-Mode Tail-Cap Switching: No

4. Build, Construction and Grip

The Blue Spectrum Mini Maglite® AA LED is built around a compact aluminum body measuring approximately 6.607 inches (167.8 mm) long. Its slim profile provides more gripping surface than the keychain-sized Solitaire® while remaining compact enough for pockets, flight bags, field kits, hunting gear, forensic equipment, inspection kits, emergency supplies, and tool bags.

The cylindrical body incorporates a deeply grooved textured grip for secure handling and easier rotation of the head during power and focus adjustments. The Spectrum configuration uses a black body with a blue accent identifying the blue Spectrum LED.

• Construction: Aluminum

• Body Style: Compact

• Body Color: Black

• Spectrum Identification: Blue Accent

• Grip: Deeply Grooved Textured Body

• Length: 6.607 in. / 167.8 mm

• Barrel Diameter: 0.709 in. / 18 mm

• Head Diameter: 1 in. / 25.4 mm

• Weight with Batteries: 4.15 oz. / 117.75 g

5. Power Source

The Blue Spectrum Mini Maglite® AA LED operates from two AA alkaline batteries, providing a widely available replaceable power source with substantially more battery capacity than smaller AAA-powered lights.

Two AA alkaline batteries are included. The flashlight is not rechargeable, so no charging cable, charging port, charging cradle, or proprietary rechargeable battery is required. Depleted batteries can simply be replaced, making the flashlight convenient for field kits, hunting equipment, flight bags, forensic and inspection kits, emergency supplies, and professional tool bags.

• Battery Type: AA Alkaline

• Battery Quantity: 2

• Battery Configuration: 2-Cell AA

• Batteries Included: Yes

• Rechargeable: No

• High Runtime: 12 hr.

• Low Runtime: 32 hr.

• Maximum Output: 27 lumens

• Low Output: 8 lumens

6. Protection and Seal

The Blue Spectrum Mini Maglite® AA LED is designed with water-resistant protection, helping protect the flashlight against water exposure encountered during everyday, field, inspection, outdoor, and professional use.

The flashlight is also rated for 1-meter drop resistance, adding durability against accidental drops during regular use. Its aluminum housing, water-resistant construction, protected LED system, and impact resistance provide a durable platform for repeated everyday and professional use.

• Water Resistant: Yes

• Drop Resistance: 1 m / approx. 3.3 ft.

• Housing: Aluminum

• Light Source: Blue Spectrum LED

• Maximum Output: 27 lumens

• Beam Distance: 71 m

• Peak Beam Intensity: 1,259 cd

Full Specifications

• Product Name: Maglite® Blue Spectrum Mini Maglite® AA LED Flashlight

• Series: Maglite® Spectrum Series

• Product Type: Compact / Everyday-Carry Pocket-Sized Two-AA Blue LED Flashlight

• Light Source: Blue Spectrum LED

• Beam Color: Blue

• Maximum Output: 27 lumens

• Low Output: 8 lumens

• Beam Distance: 71 m / approx. 233 ft.

• Peak Beam Intensity: 1,259 cd

• Runtime – High: 12 hr.

• Runtime – Low: 32 hr.

• Runtime – Eco: N/A

• LED Thermal Management: LED Heat-Sink Technology

• Power Management: Yes

• Switching: Twist-Head Operation

• High Mode: Yes

• High Output: 27 lumens

• Low Mode: Yes

• Low Output: 8 lumens

• Eco Mode: No

• Beam Focus: Adjustable Spot to Flood

• Focus Control: Rotating Head

• Hands-Free Function: Candle Mode

• Battery Type: AA Alkaline

• Battery Quantity: 2

• Battery Configuration: 2-Cell AA

• Batteries Included: Yes

• Rechargeable: No

• Construction: Aluminum

• Body Color: Black

• Spectrum Accent: Blue

• Grip: Deeply Grooved / Textured Body

• Length: 6.607 in. / 167.8 mm

• Barrel Diameter: 0.709 in. / 18 mm

• Head Diameter: 1 in. / 25.4 mm

• Weight with Batteries: 4.15 oz. / 117.75 g

• Water Resistant: Yes

• Drop Resistance: 1 m / approx. 3.3 ft.

• Specialized Applications: Low-light map and chart reading, viewing map symbols and elevation markings, blood tracking, forensic and crime-scene work, quality inspection, hygiene auditing, field work, and other specialized blue-light applications

Product Name: Maglite® Blue Spectrum Mini Maglite® AA LED Flashlight
Series: Maglite® Spectrum Series
Product Type: Compact / Everyday-Carry Pocket-Sized Two-AA Blue LED Flashlight
Light Source: Blue Spectrum LED
Beam Color: Blue
Maximum Output: 27 lumens
Low Output: 8 lumens
Beam Distance: 71 m / approx. 233 ft.
Peak Beam Intensity: 1,259 cd
Runtime – High: 12 hr.
Runtime – Low: 32 hr.
Runtime – Eco: N/A
LED Thermal Management: LED Heat-Sink Technology
Power Management: Yes
Switching: Twist-Head Operation
High Mode: Yes
High Output: 27 lumens
Low Mode: Yes
Low Output: 8 lumens
Eco Mode: No
Beam Focus: Adjustable Spot to Flood
Focus Control: Rotating Head
Hands-Free Function: Candle Mode
Battery Type: AA Alkaline
Battery Quantity: 2
Battery Configuration: 2-Cell AA
Batteries Included: Yes
Rechargeable: No
Construction: Aluminum
Body Color: Black
Spectrum Accent: Blue
Grip: Deeply Grooved / Textured Body
Length: 6.607 in. / 167.8 mm
Barrel Diameter: 0.709 in. / 18 mm
Head Diameter: 1 in. / 25.4 mm
Weight with Batteries: 4.15 oz. / 117.75 g
Water Resistant: Yes
Drop Resistance: 1 m / approx. 3.3 ft.
Specialized Applications: Low-light map and chart reading, viewing map symbols and elevation markings, blood tracking, forensic and crime-scene work, quality inspection, hygiene auditing, field work, and other specialized blue-light applications
