The Mini Maglite® AA LED Flashlight is a compact, multi-mode flashlight that combines the familiar Mini Maglite® design with an efficient LED light engine, adjustable focusing system, and multiple operating functions. Using the latest ANSI performance data, it delivers a 156-meter beam distance, 6,093 candela peak beam intensity, and 127 lumens on High. High provides approximately 11 hours of runtime, while Low extends runtime to approximately 25 hours. An adjustable spot-to-flood beam, LED Heat-Sink Technology, dynamic power management, Multi-Mode Electronic switching, Candle Mode capability, machined aluminum construction, diamond-knurled grip, IPX4 water resistance, and two included AA alkaline batteries make it practical for everyday carry, home, work, outdoor use, emergencies, and travel.

1. 156-Meter Beam Reach, 6,093 Candela & Up to 25-Hour Runtime

The Mini Maglite® AA LED combines compact dimensions with useful beam reach and extended battery life. On High, its focused LED beam reaches 156 meters (approximately 512 feet) and generates 6,093 candela peak beam intensity, providing concentrated illumination for viewing objects at distance.

High provides approximately 11 hours of runtime. Low reduces output to conserve battery power and extends runtime to approximately 25 hours. Maximum output on High is 127 lumens.

• Beam Distance: 156 m / approx. 512 ft.

• Peak Beam Intensity: 6,093 cd

• Runtime – High: 11 hr.

• Runtime – Low: 25 hr.

• Maximum / High Output: 127 lumens

• Light Source: LED

2. LED Heat-Sink Technology, Dynamic Power Management & Adjustable-Focus Head

The Mini Maglite® AA LED uses an advanced LED light engine with LED Heat-Sink Technology to help manage heat generated by the LED and support dependable performance. Dynamic power management electronically manages available battery power for efficient operation across its different output settings.

The flashlight also incorporates Maglite®'s adjustable spot-to-flood focusing system. Rotating the head changes the beam from a concentrated spot for greater reach to a wider flood for illuminating a broader nearby area. This gives the user direct control over the beam pattern without requiring separate optics or attachments.

• Light Source / Technology: LED

• Thermal Management: LED Heat-Sink Technology

• Power Management: Dynamic

• Focus System: Adjustable Spot-to-Flood Beam

• Focus Control: Rotating Head

• Beam Distance: 156 m

• Peak Beam Intensity: 6,093 cd

• Maximum Output: 127 lumens

• Head Diameter: 1 in. / 25.4 mm

3. Multi-Mode Electronic Switching with High, Low, Blink & SOS

The Mini Maglite® AA LED uses a Multi-Mode Electronic switch that provides four selectable operating modes. High Power provides maximum brightness, while Low Power operates at a reduced output level to conserve battery power and extend runtime. Blink Mode flashes approximately once per second, and SOS Mode provides an automatic emergency signaling pattern.

The adjustable head also allows the beam to transition between spot and flood. The flashlight can additionally be configured for hands-free Candle Mode, providing broad area illumination when stationary.

• Switching System: Multi-Mode Electronic Switch

• Number of Selectable Modes: 4

• Operating Modes: High Power / Low Power / Blink / SOS

• High Power: Maximum brightness

• Low Power: Reduced output for extended battery life

• Blink Mode: Flashes approximately once per second

• SOS Mode: Automatic SOS signaling pattern

• Focus: Adjustable Spot to Flood

• Hands-Free Function: Candle Mode

• Runtime – High: 11 hr.

• Runtime – Low: 25 hr.

• Maximum / High Output: 127 lumens

• Power Management: Dynamic

4. Rugged Machined Aluminum Construction & Diamond-Knurled Grip

The Mini Maglite® AA LED is built around a rugged machined-aluminum body designed to combine durability with a compact, easy-to-handle form. Its barrel incorporates Maglite®'s characteristic diamond-knurled gripping surface, providing additional texture for secure handling.

At approximately 6.607 inches long, with a 0.709-inch barrel diameter, the flashlight remains compact enough for toolboxes, bags, vehicles, emergency kits, and everyday storage. With batteries installed, it weighs approximately 4.15 ounces / 117.75 grams.

• Construction: Rugged Machined Aluminum

• Grip: Diamond-Knurled Barrel

• Design: Compact

• Length: 6.607 in. / 167.8 mm

• Barrel Diameter: 0.709 in. / 18 mm

• Head Diameter: 1 in. / 25.4 mm

• Weight with Batteries: 4.15 oz. / 117.75 g

• Focus System: Adjustable Spot to Flood

• Maximum Output: 127 lumens

5. Two AA Alkaline Batteries for Convenient, Replaceable Power

The Mini Maglite® AA LED is powered by two AA alkaline batteries, which are included. The widely available AA format makes replacement power straightforward for home, work, travel, outdoor activities, vehicle storage, and emergency preparedness.

The flashlight is not rechargeable. Its combination of replaceable batteries and dynamic power management allows the user to select maximum illumination when needed or use Low Power to extend operation to approximately 25 hours.

• Battery Type: AA Alkaline

• Battery Quantity: 2

• Battery Configuration: 2-Cell AA

• Batteries Included: Yes

• Rechargeable: No

• Power Management: Dynamic

• Runtime – High: 11 hr.

• Runtime – Low: 25 hr.

• Maximum / High Output: 127 lumens

6. IPX4 Water Resistance & 1-Meter Drop Resistance

The Mini Maglite® AA LED is IPX4 water resistant, providing protection against splashing water and making it suitable for use in rain, damp environments, outdoor activities, and other everyday conditions where the flashlight may be exposed to moisture.

The flashlight is also rated for 1-meter drop resistance. Combined with its rugged machined-aluminum housing, the water-resistant design provides practical protection for regular home, work, vehicle, emergency, and outdoor use.

• Water Resistant: Yes

• Water-Resistance Rating: IPX4

• Drop Resistance: 1 m / approx. 3.3 ft.

• Housing: Machined Aluminum

• Beam Distance: 156 m

• Peak Beam Intensity: 6,093 cd

• Maximum Output: 127 lumens

Full Specifications

• Product Name: Mini Maglite® AA LED Flashlight

• Product Type: Compact / Everyday-Carry Multi-Mode LED Flashlight

• Light Source: LED

• LED Thermal Management: LED Heat-Sink Technology

• Beam Distance: 156 m / approx. 512 ft.

• Peak Beam Intensity: 6,093 cd

• Runtime – High: 11 hr.

• Runtime – Low: 25 hr.

• Maximum / High Output: 127 lumens

• Number of Selectable Modes: 4

• Operating Modes: High Power / Low Power / Blink / SOS

• High Power: Maximum brightness

• Low Power: Reduced-output setting for extended battery life

• Blink Mode: Flashes approximately once per second

• SOS Mode: Automatic SOS signaling pattern

• Switching System: Multi-Mode Electronic Switch

• Focus System: Adjustable Spot-to-Flood Beam

• Focus Control: Rotating Head

• Hands-Free Function: Candle Mode

• Power Management: Dynamic

• Battery Type: AA Alkaline

• Battery Quantity: 2

• Batteries Included: Yes

• Rechargeable: No

• Construction: Rugged Machined Aluminum

• Grip: Diamond-Knurled Barrel

• Length: 6.607 in. / 167.8 mm

• Barrel Diameter: 0.709 in. / 18 mm

• Head Diameter: 1 in. / 25.4 mm

• Weight with Batteries: 4.15 oz. / 117.75 g

• Water Resistant: Yes

• Water-Resistance Rating: IPX4

• Drop Resistance: 1 m / approx. 3.3 ft.

• Available Colors: Black / Red / Silver / Blue / Gray

• Packaging: Presentation Box

Product Name: Mini Maglite® AA LED Flashlight
Product Type: Compact / Everyday-Carry Multi-Mode LED Flashlight
Light Source: LED
LED Thermal Management: LED Heat-Sink Technology
Beam Distance: 156 m / approx. 512 ft.
Peak Beam Intensity: 6,093 cd
Runtime – High: 11 hr.
Runtime – Low: 25 hr.
Maximum / High Output: 127 lumens
Number of Selectable Modes: 4
Operating Modes: High Power / Low Power / Blink / SOS
High Power: Maximum brightness
Low Power: Reduced-output setting for extended battery life
Blink Mode: Flashes approximately once per second
SOS Mode: Automatic SOS signaling pattern
Switching System: Multi-Mode Electronic Switch
Focus System: Adjustable Spot-to-Flood Beam
Focus Control: Rotating Head
Hands-Free Function: Candle Mode
Power Management: Dynamic
Battery Type: AA Alkaline
Battery Quantity: 2
Batteries Included: Yes
Rechargeable: No
Construction: Rugged Machined Aluminum
Grip: Diamond-Knurled Barrel
Length: 6.607 in. / 167.8 mm
Barrel Diameter: 0.709 in. / 18 mm
Head Diameter: 1 in. / 25.4 mm
Weight with Batteries: 4.15 oz. / 117.75 g
Water Resistant: Yes
Water-Resistance Rating: IPX4
Drop Resistance: 1 m / approx. 3.3 ft.
Available Colors: Black / Red / Silver / Blue / Gray
Packaging: Presentation Box
